Camden CX-ED2079 Universal Low Profile Electric Strike Grade 2, 12/24V AC/DC

The Camden CX-ED2079 is a low profile, Grade 2 electric strike for cylindrical locksets, built to release a door from the frame side on metal frames. It runs on 12/24V AC or DC and can be set in the field for fail-safe or fail-secure operation. With three stainless steel faceplates included and a non-handed design, it suits installers who want one strike for a range of door openings.

Key features

• Centerline latch entry works with cylindrical locksets.
• Accepts a latch projection of 1/2″ to 5/8″.
• Fail-safe or fail-secure operation is selectable in the field.
• The strike body adjusts horizontally to help with alignment.
• It is rated for 1000lb static strength and 50 ft lb dynamic strength.
• Buzzes on AC and runs silent on DC.

Specifications

Brand: Camden

Model: CX-ED2079

Product series: CX-ED2071/ED2079

Type: Universal low profile Grade 2 electric strike

Application: Door

Compatible lock type: Cylindrical

Compatible door frame: Metal

Door handling: Non-handed

Security configuration: Fail secure

Operating voltage: 12/24V AC/DC

Input voltage: 24V DC

Input current: 150mA

Holding strength: 1000lb

Material: Stainless steel

Color: Silver

Width: 1.85″

Height: 3.39″

Depth: 1.22″

Country of origin: Taiwan (subject to change)

Package contents: 'Universal' Low Profile Gr. 2 Electric Strike, 3 x Stainless Steel Faceplate

Installation notes

Choose the faceplate that fits your frame, then confirm the latch lines up with the strike opening and sits within the stated latch projection before final mounting. Match the power supply to the voltage you select, and test the door in both the powered and unpowered state to confirm the fail-safe or fail-secure setting works as intended.
