Fire-Lite BG-12LX Dual Action Addressable Pull Station with Key Locking Feature

The Fire-Lite BG-12LX is a dual-action addressable manual pull station that connects to an SLC loop, so occupants can signal a fire alarm by pulling the handle. It suits installers and facility managers who need a key-reset station that maintenance staff can open for inspection and addressing without triggering an alarm. A built-in bicolor LED and a latching handle marked "ACTIVATED" show the station's state at a glance.

Key features

• Maintenance personnel can open the station to inspect it and set its address without causing an alarm condition.
• The built-in bicolor LED flashes during normal operation and latches steady red in alarm.
• The handle latches in the down position and shows the word "ACTIVATED" once the station has been operated.
• Captive screw terminals come wire-ready for connection to the SLC loop.
• The station can be surface mounted or semi-flush mounted.
• It meets the ADAAG controls and operating mechanisms guidelines (Section 4.1.313) and the ADA 5lb maximum activation force requirement.

Specifications

Brand: Fire-Lite

Model: BG-12LX

Product Type: Pull Station

Product Series: BG

Input Voltage: 24V DC

Material: PC

Print/Message: Pull Down

Maximum Operating Temperature: 120°F

Country of Origin: MX

Additional Features: Key reset, key locking feature, braille text on station handle

Installation notes

Choose surface or semi-flush mounting before roughing in the box, and land the SLC conductors on the captive screw terminals. Set the device address while the station is open, then confirm it on the panel during commissioning.
