Hanwha XNB-6002 2MP Remote Head IP Camera Main Module, Black

The Hanwha XNB-6002 is a 2MP remote head IP camera main module in black, built for installers and businesses that need a compact camera head for discreet video surveillance. It captures 1920 x 1080 video at up to 60fps and pairs ExtremeWDR (120 dB) with Defog and DIS to handle difficult lighting. It also includes onboard video analytics, sound classification and a TPM 2.0 (FIPS 140-2) security module.

Key features

• Records 2 megapixel (1920 x 1080) video at 60fps in H.265 or H.264.
• Supports H.265, H.264 and MJPEG codecs, with multiple streaming.
• ExtremeWDR (120 dB), Defog and DIS help with high-contrast scenes, haze and camera movement.
• Includes advanced video analytics, sound classification and business analytics, plus Hallway View and WiseStream II.
• Accepts a microSDXC card of up to 1TB for onboard storage and supports bi-directional audio.
• Runs on PoE or 12V DC, is OnCloud compatible, and includes TPM 2.0 (FIPS 140-2).

Specifications

Brand: Hanwha

Model: XNB-6002

Product type: Remote Head Network Camera Module

Color: Black

Effective resolution: 2MP

Maximum resolution: 1920 x 1080

Aspect ratio: 16:9

Image sensor: CMOS

Maximum frame rate: 60fps

Video formats: MJPEG

Wide dynamic range: Yes

Shutter speed: 1/12000 second to 2 seconds

Input voltage: 12V DC

Cloud capabilities: Cloud enabled

Dimensions (H x W x D): 1.32″ x 5.16″ x 3.39″

Weight: 0.93 lb

Operating humidity: 90% RH (non-condensing)

Country of origin: VN

Installation notes

Plan the cable run for either PoE or a 12V DC supply before mounting, and confirm the power source matches the one you intend to use. Aim the camera at the scene during commissioning and check the image in the actual lighting conditions before settling on WDR and analytics settings.
