Episode ECA-70VMINI-60W 70V Digital Amplifier, 60W x 1 Channel

The Episode ECA-70VMINI-60W is a compact 70V digital amplifier with one 60W channel, built to drive 70V speaker lines in commercial and residential audio installs. It suits TV audio in restaurants, bars and conference rooms, and it can also improve the sound of outdoor speakers. With three inputs and an external 12VDC power supply included, it is a small, simple way to add 70V capability to a room.

Key features

• Compact 70V digital amplifier that still delivers solid power.
• Built for clear, high-quality audio output.
• Well suited to TVs in restaurants, bars and conference rooms.
• Helps outdoor speakers sound better.
• Three inputs let you connect multiple sources.
• Comes with an external 12VDC power supply.

Specifications

Brand: Episode

Model: ECA-70VMINI-60W

Product Type: 70V Amplifier

Product Line: MRA

Channels: 1

Power Rating: 60.00W

Maximum Power Consumption: 60.00W

Power Consumption: 30.0000W

Connector Type: RCA

Maximum Frequency Response: 20kHz

Total Harmonic Distortion (THD): 0.5% – 1%

Features: 4mV Auto On Sensitivity

Compatibility: Control4

Certifications: CE

OvrC Enabled: No

Dimensions: 10.5″ x 6.3″ x 1.75″

Rack Width: 8.0″

Installation notes

Place the amplifier where it has some airflow and can be reached for input and speaker wiring, and keep the low-level RCA runs short and away from power cabling to limit noise. Confirm the total speaker load on the 70V line stays within the amplifier's power rating before commissioning.
