STI 6400 Exit Stopper Multifunction Door Alarm, Red

The Von Duprin 6400 Series Electric Strike (model 6400-US32D-12/24VDC-FSE) is a fail secure electric strike that releases a door's latch electrically so it can be opened from the access side. It suits installers and facility owners fitting cylindrical or mortise locks on metal frames. Its modular design, stainless steel build and latchbolt monitor feature stand out.

Key features

• The modular design fits cylindrical locks and nearly any mortise lock.
• Heavy-duty stainless steel construction comes in a BHMA 630 satin finish.
• Vertical adjustments let you align the strike with mortise locks that have offset latches.
• A latchbolt monitor feature is included.
• The fail secure configuration keeps the door locked if power is lost.

Specifications

Model: 6400-US32D-12/24VDC-FSE

Brand/Vendor: Von Duprin

Product Series: 6400

Product Type: Electric Strike

Application/Usage: Door

Security Configuration: Fail Secure

Compatible Door Lock Type: Cylindrical

Compatible Door Frame Type: Metal

Door Handling: Non-Handed

Features: Latchbolt Monitor

Material: Stainless Steel

Finish: BHMA 630 satin

Color: Silver

Width: 1.25″

Height: 4.88″

Input Voltage: 12V DC

Input Current: 190mA

Holding Strength: 1500lb

Country of Origin: US

Installation notes

Check the lock's latch position against the strike before cutting the frame, and use the vertical adjustment to line up offset latches. Confirm the power supply matches the strike's DC input voltage and can carry its current draw, then test the release and the latchbolt monitor with the door closed before handing the system over.
