Eaton ELMTSW Wheelock Eluxa Multitone Strobe Horn, FIRE Lettering, Wall Mount, 24V, White

Eight distinct alerting sounds in one compact wall-mounted device—Horn, Bell, March Time Horn, Code-3 Tone, Code-3 Horn, Slow Whoop, Siren, and Hi/Lo Tone. Engineered to comply with NFPA/ANSI Temporal Pattern specifications and meets NFPA 72 fire and CO low frequency sounder codes for sleeping rooms without requiring additional equipment.

Advanced LED technology delivers industry-leading efficiency with the lowest current draw across all candela settings, reducing power consumption and system costs. Six candela options (15, 30, 75, 110, 135, 185 cd) accommodate various indoor applications. As the first notification appliances to use LED as the light source, this breakthrough design enables material and system cost savings while supporting more appliances per circuit.

Features include two sound output levels (Standard and High dBA), low-profile design, and pre-wire/pre-test capability via hinged mounting plate for simplified installation. Dual input terminals allow audible and strobe to operate simultaneously from one input or independently from two inputs using 4-wire configuration.

UL and CAN/ULC listed under Standards 1638, 464, S525, and S526. Also CSFM and FM approved. RoHS compliant with no mercury or hazardous substances. Fully compatible with all Fire Alarm Control Panels and backward compatible with existing Wheelock RSS strobe models for mixed installations.

24V operation with filtered or unfiltered input voltage support. Includes mounting plate. White housing with FIRE lettering. Clear lens. Indoor use only.
